A network diagram is a visual representation of a computer network or project management strategy. It provides a schematic or map of the network's existing topology, illustrating nodes and their connections. These diagrams can be used to represent virtually any network and can be physical or logical. Physical network diagrams show the physical arrangement of components, while logical network diagrams describe the flow of information through a network. Logical diagrams may include physical attributes or exclude them, focusing on the network topology. The level of detail in a network diagram depends on its scope and purpose. For example, a basic network diagram may provide a simplified view of information flow for new employees, while more detailed diagrams can help optimize network architecture and troubleshoot issues. In project management, network diagrams help track project schedules and progress, providing a visual representation of the project's scope and facilitating better communication and coordination within the team.
| Characteristics | Values |
|---|---|
| Purpose | To provide a big-picture overview or a detailed view of the network |
| Scope | Can be broad or detailed, depending on the network and its purpose |
| Type | Physical or logical |
| Topology | Star, bus, ring, mesh, tree, hybrid |
| Visuals | Boxes, arrows, nodes, symbols, icons |
| Information | IP addresses, device names, connection types, network devices, routing protocols, subnets, VLAN IDs, masks, addresses |
| Use | Planning, documentation, troubleshooting, compliance, project management |
Explore related products
What You'll Learn
Physical vs. logical network diagrams
A network diagram is a schematic or map of a network that illustrates the nodes and their connections. It can be used to represent virtually any network and can be used to map out the schedule and work sequence for a project, as well as track its progress.
Network diagrams can be classified as either physical or logical. A physical network diagram shows the physical arrangement of the components that make up the network, including cables and hardware. It gives a bird's-eye view of the network in its physical space, similar to a floor plan. Physical diagrams show the physical assets inside buildings, floors, and rooms, and how they are connected.
A logical network diagram, on the other hand, describes the way information flows through a network. It shows subnets (including VLAN IDs, masks, and addresses), network devices like routers and firewalls, and routing protocols. Logical diagrams typically exclude physical details like link information and may even omit entire groups of devices, focusing instead on the flow of data between devices.
The logical and physical topology of a network may resemble one another, or they may be entirely different. For example, a twisted-pair Ethernet network has a star topology physically but follows a bus topology logically.
Both types of diagrams are important for documentation and troubleshooting. Physical diagrams provide a more "accurate" representation of the physical layout of a network, while logical diagrams are often preferred by network administrators as they offer insight into how data is transmitted and how devices communicate.
