Designing Structural Steel: Understanding Braced Points For Diagonal Braces

what constitutes a braced point for structural steel diagonal braces

Structural steel diagonal braces are an essential component in the construction process, ensuring the stability of the overall structure and its individual components. They are often used to compensate for a reduced number of exterior columns, resulting in a significant decrease in construction costs. Diagonal braces can take lateral loads in axial action, minimising shear lag. They are also effective in reducing the effects of wind and providing stability in earthquake-prone areas. The two main types of diagonal bracing are concentric bracing and eccentric bracing, with the former being more commonly used due to its ease of design and assembly. When designing steel-braced frames, it is crucial to direct lateral loads in horizontal beams towards angled struts, utilising the axial strength of the brace members. This results in a more stable structure that can withstand vertical forces.

Characteristics Values
Types of structural steel diagonal braces Concentric bracing, eccentric bracing, K-bracing, cross bracing (X-bracing), chevron braces
Concentric bracing Diagonal braces positioned within the frame's plane, with all members (beams, columns, and bracing) meeting at a common point
Eccentric bracing Comprised of axial loading members and bending loading members (horizontal members); used in earthquake zones due to high ductility
K-bracing Preferred for torsional bracing in multi-girder bridges
Cross bracing (X-bracing) Provides lateral resistance to lateral load from both X and Y directions
Chevron braces Used to protect structures from intense earthquakes
Materials Angle steel, round steel, galvanized steel cables, I-Sections or W-Sections (Wide Flange Beams), Angle Sections, Channel Sections
Connection Bolts are preferred over welds for ease of assembly
Design considerations Stresses, global displacements, stiffness, strength, stability, durability, ease of installation, slip resistance
Applications Buildings, bridges, industrial factories, crane systems, steel gate structures

cycivic

Bracing system design principles

Bracing systems are an essential part of structural design, providing stability and strength to steel structures. Here are some key design principles for bracing systems:

Load Distribution

The primary function of a bracing system is to resist and distribute lateral loads, such as wind and seismic forces. The system should be designed to direct these loads through the structure in the shortest and most direct way, reducing stress concentrations. This ensures the structure remains stable and strong under various load conditions.

Bracing Types

There are several types of bracing arrangements to choose from, each with its advantages and disadvantages. Common bracing types include:

  • Diagonal Bracing: This type of bracing is often used in vertical and horizontal planes to provide lateral stability. Diagonal braces can take lateral loads in axial action, reducing shear lag.
  • Cross Bracing (X-Bracing): This bracing uses a diagonal design to spread horizontal loads, creating a clear path for the load and boosting stability.
  • K-Bracing: K-bracing has fewer members intersecting at joints, reducing welding and assembly costs. However, it has less redundancy than X-bracing.
  • V-Bracing: This type of bracing is often used alongside other systems to reinforce structural stability.

Structural Integration

The bracing system should seamlessly integrate with the architectural design, providing strong resistance to loads while maintaining the design's integrity. This balance between strength and aesthetics ensures both structural integrity and visual appeal.

Material Choice

The choice of material for the bracing system is crucial. Steel bracing, for example, can add stiffness to a structure, enhancing its resistance to buckling. Additionally, steel is often used in conjunction with concrete, as the concrete restrains the bracing against buckling.

Earthquake Resilience

In earthquake-prone areas, energy-dissipating bracing systems, such as buckling-restrained braces (BRBs) and viscous dampers, are essential. These systems absorb and redistribute seismic forces, protecting the structure from damage during earthquakes.

By following these design principles, engineers can create effective bracing systems that ensure the safety and stability of steel structures under a range of load conditions.

cycivic

Bracing member materials

Steel bracings are essential in providing stability to multi-storey buildings. They are often used in conjunction with concrete cores, with the steel diagonals transferring loads to the vertical concrete elements. This combination of steel and concrete allows for economical construction without compromising structural integrity.

The arrangement of steel bracing members can vary depending on the specific requirements of the structure. Vertical bracing bays, for instance, consist of angled steel struts or tie members that span diagonally between orthogonal beams and columns. They are typically positioned in vertical planes, between columns, or within partition walls to provide discrete structural support while maintaining architectural aesthetics.

In terms of structural behaviour, tension members are generally preferred for steel bracing elements as they are less susceptible to buckling compared to compression members. To optimise the performance of steel bracing, members are often placed at 45 degrees to achieve a beam-column juncture. This angle helps to minimise the sway sensitivity of the structure.

Additionally, steel bracing can be designed as concentric or eccentric bracing. Concentric bracing involves diagonal braces positioned within the frame's plane, connecting at the endpoints of another framing member. Eccentric bracing, on the other hand, does not connect at these endpoints, which helps prevent buckling under large loads by reducing the effective length of the braces.

Furthermore, steel bracing can be applied in various types of bracing systems, such as torsional bracing and horizontal bracing. In torsional bracing, the K-type bracing is commonly used in multi-girder bridges, while horizontal bracing can be in the form of cross-ties for roofs, providing tension-only resistance.

cycivic

Bracing member placement

The placement of bracing members is critical to the stability of the structure and is influenced by various factors, including the type of structure, loading conditions, and design objectives. Here is a detailed guide on bracing member placement for structural steel diagonal braces:

Diagonal braces are commonly used to provide lateral stability to structures, especially in steel construction. In industrial buildings or factories with crane systems, diagonal bracing bars are placed along the column ends in both the upper and lower column ranges. This enhances the stiffness in the vertical direction of the horizontal frame, transferring lateral loads from wind, crane operations, or seismic activity to nearby frames.

Spacing and Arrangement:

The spacing and arrangement of bracing members are crucial. In steel structures, the bracing members should be placed to form a rigid block, ensuring the stability of the entire structure. The distance between braces should be carefully considered, typically not exceeding five column spans. For steel bridges, plan bracing is often placed at the top flange level, but in some cases, such as hogging moments in main girders, bracing may be required on the bottom flange as well.

Bracing Member Inclination:

The inclination of braced (diagonal) members is important. Placing these members at a 45-degree angle helps achieve a beam-column juncture. Inclinations less than 45 degrees will increase the sway sensitivity of the structure.

Bracing Member Connection:

Bracing members are typically connected with bolts rather than welds, allowing for easy assembly on-site. Slip-resistant connections are generally used to ensure the stability and security of the structure.

Design Considerations:

When designing the bracing system, engineers should focus on transmitting vertical loads efficiently, minimising the load transmission path, and providing lateral support points to fix and stabilise the overall structure and its components. The bracing system should also facilitate ease of structure installation and meet the required strength and stiffness criteria.

In summary, the placement of bracing members in structural steel diagonal braces is a critical aspect of ensuring the stability and functionality of the structure. By following the guidelines outlined above, engineers can effectively design and position bracing members to meet the specific requirements of their projects.

cycivic

Bracing member connections

Connection Techniques:

Bracing members are typically connected through bolting to a gusset plate, which is then welded to either the beam or the column. This bolting and welding combination provides a secure and robust connection. In some cases, fully welded connections, such as hollow section K-joints, may be utilised. The choice between bolting and welding depends on the specific design requirements and constraints.

Design Considerations:

When designing bracing member connections, it is crucial to consider the type of bracing system employed, such as torsional bracing or lateral bracing. The loads acting on the structure, including lateral loads and shear forces, must be carefully analysed to ensure the connections can withstand these forces. Additionally, the stiffness of the bracing members and the overall structure should be considered to optimise their interaction.

Software and Modelling:

Advancements in software, such as IDEA StatiCa and FEM, have revolutionised the design process by enabling detailed modelling and analysis of bracing member connections. These tools allow engineers to simulate various loading conditions and predict the behaviour of connections, ensuring their effectiveness and safety.

Specialised Connections:

In certain cases, specialised connection techniques may be required, such as cap and base plate splices in column bases. These connections need to be designed with adequate stiffness to ensure their structural integrity. Additionally, in projects like diagrid structures, full-scale testing and finite element modelling are employed to design nodes that can effectively manage different loading scenarios.

Aesthetic Considerations:

In some instances, clients may desire to showcase the bracing system as a design feature, as seen in the Midland Metropolitan Hospital. This integration of functionality and aesthetics requires careful planning and creativity in designing the bracing member connections.

By following these considerations and utilising appropriate connection techniques, engineers can ensure that bracing member connections are robust, safe, and tailored to the specific requirements of each structure.
