Atoms In An Fcc Unit Cell: Counting Atoms

Crystalline solids are defined by the arrangement of their unit cells, which dictates their structure and symmetry. A crystal lattice is the three-dimensional arrangement of atoms, molecules, or ions inside a crystal. The number of atoms in one face-centred cubic (FCC) unit cell can be determined by the number of atoms contributed by the faces and corners of the unit cell. There are eight corners with one-eighth of an atom per corner, and six faces with half an atom per unit face. This totals to four atoms per unit cell, making it an asymmetric structure.

Explore related products

1pc JG-59 Face-centered cubic stacking model ABC ball-and-stick crystal

$132

Face-centered cubic structure high-entropy alloy(Chinese Edition)

$38.9

Experimental Investigation of Crack Initiation in Face-Centered Cubic Materials in the High and Very High Cycle Fatigue Regime

$77

Metal Crystal Structure Model Chemical Organic Molecules and Inorganic Crystals Scale Assembly Model for Chemistry Learning Tool

$125

Carleen 14k Solid Gold CZ Simulated Diamond Small Cute Dragonfly Necklace Dainty Delicate Everyday Fine Jewelry Statement Pendant Valentines Day Gifts for Women Girls, 16+2" Gold Chain

$299

Square Glossy Women's Fashion Ring with 3mm Zirconia Center and Double Row Micro Zirconia Accents in Rose Gold Plated Copper

$15.99

A unit cell is the most basic unit of a crystal lattice

A unit cell is the most basic and smallest unit of a crystal lattice. It is the simplest repeating unit in a crystal structure. The entire lattice is generated by the repetition of the unit cell in different directions.

Unit cells can be divided into two categories: primitive and centered unit cells. A primitive unit cell is formed when the constituent particles occupy only the corner positions. In this case, the effective number of atoms of the unit cell is one. When the constituent particles occupy other positions in addition to those at the corners, it is known as a centered unit cell.

The number of atoms in a face-centered cubic (FCC) unit cell can be determined by considering the contributions from the faces and corners of the unit cell. Each corner of the unit cell contributes 1/8 of an atom, and there are eight corners in total, resulting in one atom. Additionally, each face contributes 1/2 an atom, and with six faces, this results in a total of three atoms. Therefore, the FCC unit cell contains four atoms.

The structure of a crystal can be visualized as a repeated element in three dimensions, with the unit cell acting as the building block. In three-dimensional space, the unit cell is defined as a parallelepiped whose vertices are lattice points, while in two dimensions, it is a parallelogram with lattice points at its vertices. The lattice points in a crystal lattice represent the positions of atoms, molecules, or ions.

FCC, or Face-Centred Cubic, is an asymmetric crystal structure

Unit cells can be divided into two categories: primitive and centred unit cells. Primitive cells, or primitive unit cells, are structures with discrete translational symmetry. They are found in mathematics. The number of atoms in a unit cell's geometry is no more than the number of coordinates held by each atom. The hexagonal closest packed (HCP) crystal structure has a coordination number of 12 and a unit cell density of 6 atoms, making it the densest crystal structure known. The HCP structure is the most compact, with 12 coordinates and four atoms per unit cell. Cubic Close-Packed (CCP) is sometimes abbreviated as FCC in certain textbooks.

FCC crystals have 4 atoms per unit cell

Face-centred cubic (FCC) crystals have a coordination number of 12 and a unit cell size of 4 atoms. This is calculated by considering the number of atoms contributed by the faces and corners of the unit cell. Each corner of the cube contributes 1/8 of an atom, and with 8 corners, this amounts to 1 atom. Each face of the cube contributes 1/2 an atom, and with 6 faces, this amounts to 3 atoms. Therefore, the total number of atoms in one unit cell of an FCC crystal is 4.

FCC crystals are the most common crystal structure. They are formed by a Bravais lattice, with one atom per lattice point, at each corner and face of the cube. This structure is also known as Cubic Close-Packed (CCP) and is one of the most stable crystal formations.

The number of atoms in a unit cell is significant as it determines the crystal's structure and symmetry. Crystalline solids are defined by the arrangement of their unit cells. FCC crystals have a coordination number of 12, which means that each atom in the crystal is surrounded by 12 other atoms. This gives FCC crystals their unique properties, such as high melting points and mechanical strength.

The hexagonal closest packed (HCP) crystal structure is another common type of crystal lattice. HCP has a coordination number of 12 and a unit cell density of 6 atoms, making it the densest crystal structure known. It is also asymmetrical, with 12 coordinates and 4 atoms per unit cell. However, despite having the same number of atoms per unit cell as FCC crystals, the arrangement of atoms in HCP is different, resulting in distinct physical properties.

Explore related products

99.99% Pure Platinum Wire Electrode for Electrophoresis and Chemical Applications - Platinum Wire(0.09mmx50cm)

$59.49

99.99% Pure Platinum Wire Electrode for Electrophoresis and Chemical Applications - Platinum Wire(0.02mmx50cm)

$59.49

99.99% Pure Platinum Wire Electrode for Electrophoresis & Catalyst Applications - High Purity Platinum Gold Wire(0.1mmx50cm)

$62.46

99.99% Pure Platinum Wire Electrode for Electrophoresis & Catalyst Applications - High Purity Platinum Gold Wire(0.06mmx50cm)

$62.46

99.99% Pure Platinum Wire Electrode for Electrophoresis and Chemical Applications - Platinum Wire(0.07mmx50cm)

$59.49

99.99% Pure Platinum Wire Electrode for Electrophoresis & Catalyst Applications - High Purity Platinum Gold Wire(0.08mmx50cm)

$62.46

FCC is the most common crystal structure

Face-centered cubic (FCC) is the most common crystal structure. FCC and body-centered cubic (BCC) are two of the most iconic crystal structures. Nearly all elements have FCC, BCC, or HCP structures. The face-centered cubic structure has an atom at each of the 8 corner positions and at the center of all 6 faces. The total number of atoms per unit cell in an FCC structure can be calculated as: (8 corners x 1/8 atom per corner) + (6 faces x 1/2 atom per unit face) = 1 atom + 3 atoms = 4 atoms.

The cubic crystal system is one of the most common and simplest crystal classes. All crystal structures in this system have a cube-shaped unit cell. The three main representatives of this system are the simple cubic structure (also known as primitive cubic), the body-centered cubic structure, and the face-centered cubic structure. The simple cubic structure has only one atom per lattice point and is relatively rare in nature due to its low packing efficiency and low number of nearest neighbours for each atom. Polonium (Po) is one of the few elements reported to crystallize in this structure.

The body-centered cubic structure is based on the simple cubic structure but has an additional lattice point at the very center of the cube. This structure is more common in nature than the simple cubic structure due to its slightly higher packing efficiency and nearest neighbour interaction. Some prominent metallic solids with this structure are iron (Fe), chromium (Cr), and tungsten (W).

The face-centered cubic structure, on the other hand, has lattice points at each corner and additional lattice points at the center of each face of the cube. This structure is very common for metallic elements as it maximizes packing efficiency and has the highest number of nearest neighbours, increasing its stability. Some common FCC metals at room temperature are aluminum, nickel, and copper.

The FCC structure is also known as the cubic close-packed structure. It is important to note that the term fcc is often used synonymously with the cubic close-packed or ccp structure occurring in metals. However, FCC stands for a face-centered cubic Bravais lattice, which is not necessarily close-packed when a motif is set onto the lattice points. For example, the diamond and zincblende lattices are FCC but not close-packed.

FCC is also known as Cubic Close-Packed

A face-centered cubic (FCC) crystal lattice is also known as a cubic close-packed structure. This is because the FCC structure is one of the two simple regular lattices that achieve the highest average density, along with the hexagonal close-packed (HCP) structure. The FCC arrangement produces a tetrahedral-octahedral honeycomb, while the HCP arrangement produces a gyrated tetrahedral-octahedral honeycomb.

The FCC structure gets its name from its geometry. The unit cell in an FCC crystal lattice is a cube with an additional atom at the center of each face. This means that the FCC structure has a coordination number of 12 and contains 4 atoms per unit cell. The number of atoms in one unit cell can be determined by counting the number of atoms contributed from the faces and corners of the unit cell.

The FCC structure was first mathematically analyzed by Thomas Harriot around 1587 after Sir Walter Raleigh posed the "cannonball problem" to him. Cannonballs were usually piled in a rectangular or triangular wooden frame, forming a three-sided or four-sided pyramid. Both arrangements produce an FCC lattice, with the cannonballs forming the vertices of a triangular tiling.
